Estar Economy LED Cabinet Lights
Click or Tap the orange menu button to view all Estar LED Tech page links
Estar LED Tech Co. LED Cabinet Lights
We found an awesome LED light that is the answer for new installations as well as retrofitting. On this page we will show your choices for the recess mounted LED light and the colored Trim Rings to cover the face of the light. You have five options for the trim rings: White, Black, Brushed Nickel, Polished Chrome, and Polished Gold. Thus, we have found a light to match all 5 colors that the old Hera Halogen lights came in. Great news for boat owners. Even better that these LED lights are 12 volt. You can run them directly from the 12Vdc on your boat. Or within your home, you can use the LED power driver to convert your 120Vac to 12Vdc. Thus, this particular LED light is going to fill A LOT OF HOLES.
For new installations:
If installing in your home as under cabinet lighting, either in the kitchen, bathroom, bedroom, home office or anywhere you are planning some under cabinet lights, you will also look at the following web pages:
- Estar LED power drivers
- Estar LED lights surface mount rings
- Dimming accessories for Estar LED lights (coming soon when we receive some dimmers)
Each light has an attached lead wire with a coupler on the end. That coupler easily connects into the LED power driver, and the terminal block extenders for the drivers shown on the LED drivers page. You can create your own 3-light, 4-light, up to 16-light kits since you can run 16 lights on a 60 watt driver with one terminal block extender. Thus long runs of light, no problem. You can create a lot of beautiful in-cabinet and under cabinet lighting in your application.
Then for anyone needing to surface mount the lights instead of recess mounting, you do have the same 5 finish choices in decorative surface mount rings. Surface mounting is not as common. But sometimes you run into an application where is makes more sense. So these optional rings give you possibilities.
For Renovating from older Halogen or LED recessed lights
If in your home, you will need to use the number of lights that you need, and at least one LED power driver. If you have multiple zones of lights which are controlled independently, you will need an LED driver per zone. This LED light can fit into several different recessed sized holes. On our web page: How to Recess LED Cabinet Lights we will explain MUCH more.
For marine vessels: Again, this light can fit many holes. We show examples on the how to recess LED cabinet lights page. Each light has a twin wire lead wire and a coupler on the end. Most likely you will nip off that coupler and then splice the two wires into your existing wiring. Very easy to do with butt connectors. And if you have any lights that are surface mounted, visit our surface mount rings page to order the rings that conver the light to a surface mount light.
Now, your Light Choices
Specs on the lights will follow these 3 choices.
SELT-WD-UL008-2700K
Estar LED Tech: LED Cabinet Lights
Estar Tech Co. WD-UL008-2700K 12 volt LED light, 2700K warm white, 3 watt, 110 lm/W, CRI >90Ra, 22mm tall, designed for 60mm recess, but will fit into 2-1/8" dia. hole
$19.84
Add
SELT-WD-UL008-3000K
Estar LED Tech: LED Cabinet Lights
Estar Tech Co. WD-UL008-3000K 12 volt LED light, 3000K warm white, 3 watt, 110 lm/W, CRI >90Ra, 22mm tall, designed for 60mm recess, but will fit into 2-1/8" dia. hole
$19.84
Add
SELT-WD-UL008-4000K
Estar LED Tech: LED Cabinet Lights
Estar Tech Co. WD-UL008-4000K 12 volt LED light, 4000K cool white, 3 watt, 110 lm/W, CRI >90Ra, 22mm tall, designed for 60mm recess, but will fit into 2-1/8" dia. hole
$19.84
Add
Specifications follow next for these lights.
But after that, the trim rings that you use to complete the decorative look of your light. Trim rings cover the face to hide the white casing. They magnetically hold. No ugly screws showing.
Specifications on the WD-UL008 lights
Clicking any picture above will give you the option to see the backside of the light
- Each light is 3 watts, choices of 2700K warm white, 3000K warm white, or 4000K cool white
- CRI > 90, 12 volt LED light
- Lumen output: 110lm/W
- Recommended cut out size for recessing for new installation is 60mm (2-3/8")
- We have tested that this light will fit into the popular Hera 2-1/8" dia. hole
- Lights are friction fit, but can also be screw mounted
- Each light has a 79" long preattached connecting wire
- Overall face diameter with trim ring is 3.15 inches, thus great choice for old Hera H11 lights on boats
- Choice of 5 trim ring colors: White, Black, Brushed Nickel, Polished Chrome, Polished Gold (shown next on this page)
- Recess depth required 22mm (3/4")
- Can easily connect 1 to 6 lights on the 60 watt LED driver
- With the aid of one 10-port terminal block extender, you can connect up to 16 lights on one driver
- Surface mounting availble: see the surface mount rings page
Now your choices in Trim Rings
SELT-008TBK
Estar LED Tech: LED Light Accessories
Estar LED Tech Co. 008TBK trim ring for LED light, magnetic mount, overall dia. 3.15", matte black finish
$1.77
Add
SELT-008TWT
Estar LED Tech: LED Light Accessories
Estar LED Tech Co. 008TWT trim ring for LED light, magnetic mount, overall dia. 3.15", matte white finish
$1.77
Add
SELT-008TBN
Estar LED Tech: LED Light Accessories
Estar LED Tech Co. 008TBN trim ring for LED light, magnetic mount, overall dia. 3.15", brushed nickel finish
$1.96
Add
SELT-008TCH
Estar LED Tech: LED Light Accessories
Estar LED Tech Co. 008TCH trim ring for LED light, magnetic mount, overall dia. 3.15", polished chrome finish
$1.96
Add
SELT-008TGD
Estar LED Tech: LED Light Accessories
Estar LED Tech Co. 008TGD trim ring for LED light, magnetic mount, overall dia. 3.15", polished gold finish
$1.96
Add
About the Trim Rings
- All 5 choices are metal, NOT PLASTIC
- They magnetically hold to the face of the light. Look at the light, see the two silver spots in the white collar? Those are the magnets.
- Overall diameter is 3.15 inches. When light is recessed mounted, surface protrusion with ring is .16" (just over 1/8")
- The hole dia. in the ring is 1.45", so about 1-1/2". Very similar in size to the old halogen lights.
- Thus the rim is wider, which is nice for covering a greater surface diameter or miscolored areas when retrofitting
For more indepth information on mounting these LED lights, we have these two pages set up:
Lots to say, so we put the info on additional pages.
What to order:
Order the number of lights that you need in the 2700K, 3000K, or 4000K. The 3000K are the most popular choice. The warm white glow is very similar to halogen lighting. This is favored by most people. Some like the 2700K light output which is even warmer. It will have more of an orange-hue glow. And then the 4000K is a cleaner more white type light output. A more indepth explanation about the Kelvin rating on the lights, with pictures, will be on our More About Estar LED Lighting page.
For home use, you will want to select one or more LED power drivers. There are also terminal block extenders and extension lead wires shown on that web page. If ordering lights for your boat and running them from your 12Vdc, you DO NOT need the LED power driver. Driver is for converting 120Vac to 12Vdc.
ORDER ONE TRIM RING per light. Trim rings come separately. Part numbers are shown above. You have 5 color choices to select from. If needing surface mount rings, those are on the surface mount rings page.
If you have any questions, we are here to help. Not around the clock, just 9 to 5 Mon. to Fri. and occasional 12 to 3 on Saturdays. We do tend to answer some e-mails in the evenings. And we generally try to get back to inquiries by the next business day. Our contact links are in the header and footer of all web pages.
