Kitchen Trash Cans Door Mountable Slide Outs
Hafele Pull-Out Waste Bin Management Systems
These are some of the top of the line when it comes to kitchen slide out trash cans. The Hafele Hailo US Cargo waste bin pull-outs are elite side mounted trash bin systems. Not bottom mounted like others. Bins suspend in their strong steel frame capable of supporting up to 110 pounds. I take out the trash in my house, and in my 35 quart slide out that I have, the bag seldom exceeds 20 to 25 pounds. So with a 110 pound capacity, doubtful that you would ever come close to that.
Kitchen conveniences are one of the big things that makes it desirable to be in your kitchen. If anyone remembers their grandparents or great-grandparents house, odds are it was a pretty small house. And sometimes half of the kitchen was taken up with the dining room table side tables, and even a klunky unattractive trash can. The trash can either sat in the corner of the kitchen, or a tiny tiny can was kept under the sink. And it had to be tiny because that is where all the plumbing pipes hung down and there was not much room in that cabinet.
In today's houses, kitchens are not so tiny anymore. Most of the time they are a focal point that is open to the main living room. Kitchens are generally accessible from two sides. The dining room table is in an area of its own now. And trash cans are hidden in a full size cabinet, and are more fancy single and double bin slide out units. Many attached to the door so when you pull on the door, the trash can is there and ready to be used. And ready to be pushed back out of plain view when not needed.
FF units for Face Frame Cabinets
- For face frame cabinets, very popular in today's new kitchens
- Side mounted
- Unit fits below a drawer
- Has soft close synchronized progressive slides (very quiet)
- For cabinet sidewall thicknesses of 5/8" to 3/4", or greater
- Minimum inside cabinet depth (behind face frame) of 22" required, if deeper, that is okay
- Minimum height opening of 20-1/2" required, if greater, that is okay
- Face frame opening width range listed with each product description below
- Maximum weight capacity spread out to both bins is 110 pounds, which you should never have that much trash at one time
- Lid and frame are steel, powder coated grey finish
- Bins are polymer plastic, light grey finish
Note that there are 4 width sizes to select from. Measure the width of your face frame opening. Door mount brackets are optional, and a nice option to have.
If you would like to review installation diagrams for the face frame units, select that link to open a PDF file.
Hafele Waste Bin Pull-Outs
Hafele 502.77.521 waste bin pull-out, Hailo US Cargo FF15, for face frame cabinet, 13-1/2 to 14-1/16" opening width range, 22" depth, 20-1/2" overall height, 110 pound weight capacity, light grey plastic bins 39 qt and 15.9 qt sizes
$459.60
Add
Hafele Waste Bin Pull-Outs
Hafele 502.77.522 waste bin pull-out, Hailo US Cargo FF18, for face frame cabinet, 16-1/2 to 17-1/16" opening width range, 22" depth, 20-1/2" overall height, 110 pound weight capacity, light grey plastic bins 39 qt and 15.9 qt sizes
$470.66
Add
Hafele Waste Bin Pull-Outs
Hafele 502.77.523 waste bin pull-out, Hailo US Cargo FF21, for face frame cabinet, 19-1/2 to 20-1/16" opening width range, 22" depth, 20-1/2" overall height, 110 pound weight capacity, light grey plastic bins two at 44.4 qt each
$480.91
Add
Hafele Waste Bin Pull-Outs
Hafele 502.77.524 waste bin pull-out, Hailo US Cargo FF24, for face frame cabinet, 22-1/2 to 23-1/16" opening width range, 22" depth, 20-1/2" overall height, 110 pound weight capacity, light grey plastic bins two at 44.4 qt each
$544.86
Add
Hafele Waste Bin Pull-Outs
Hafele 502.77.990 Overlay Door Bracket Kit for full overlay applications, use with Hailo US Cargo pull-out waste bin systems
$37.20
Add
Full Access for Frameless Cabinets (Euro box cabinets)
- Side mounted
- Unit fits below a drawer
- Has soft close synchronized progressive slides (very quiet)
- For cabinet sidewall thicknesses of 5/8" to 3/4", or greater
- Minimum inside cabinet depth of 22" required, if deeper, that is okay
- Minimum height opening of 20-1/2" required, if greater, that is okay
- Maximum weight capacity spread out to both bins is 110 pounds, which you should never have that much trash at one time
- Lid and frame are steel, powder coated grey finish
- Bins are polymer plastic, light grey finish
Note that there are 4 width sizes to select from, for both the face frame and frameless models. The width opening range is listed for each unit. If your opening happens to be a little larger than the range listed, you can still make the unit work. You would need to pack out the side walls with spacers, such as washers or thin blocks of wood. Slides are side mounted, so if you create something that allows the sidewalls to meet up closer to the slides, you can make the unit work in openings greater than shown. On the face frame models, you would also need to build out the edges of the face frame to even out with what you build out on the side walls. A little bit of work, but these Elite slide out units can be made to work in a variety of cabinets.
If you would like to review installation diagrams for the full access units, select that link to open a PDF file.
Hafele Waste Bin Pull-Outs
Hafele 502.77.531 waste bin pull-out, Hailo US Cargo 15 Full Access, for frameless cabinet (Eurobox), 13-1/2 to 13-3/4" opening width range, 22" depth, 20-1/2" overall height, 110 pound weight capacity, light grey plastic bins 39 qt and 15.9 qt sizes
$449.76
Add
Hafele Waste Bin Pull-Outs
Hafele 502.77.532 waste bin pull-out, Hailo US Cargo 18 Full Access, for frameless cabinet (Eurobox), 16-1/2 to 16-3/4" opening width range, 22" depth, 20-1/2" overall height, 110 pound weight capacity, light grey plastic bins two at 39 qt each
$457.95
Add
Hafele Waste Bin Pull-Outs
Hafele 502.77.533 waste bin pull-out, Hailo US Cargo 21 Full Access, for frameless cabinet (Eurobox), 19-1/2 to 19-3/4" opening width range, 22" depth, 20-1/2" overall height, 110 pound weight capacity, light grey plastic bins two at 44 qt each
$467.79
Add
Hafele Waste Bin Pull-Outs
Hafele 502.77.534 waste bin pull-out, Hailo US Cargo 24 Full Access, for frameless cabinet (Eurobox), 22-1/2 to 22-3/4" opening width range, 22" depth, 20-1/2" overall height, 110 pound weight capacity, light grey plastic bins two at 44 qt each
$528.06
Add
Hafele Waste Bin Pull-Outs
Hafele 502.77.990 Overlay Door Bracket Kit for full overlay applications, use with Hailo US Cargo pull-out waste bin systems
$37.20
Add
Please take note of the dimensions listed with every unit above. These are the MINIMUM size opening for height and depth that you must have in order for the waste slide out unit to fit in your "opening." Then the width "range" for opening size is listed with each sise. Some kitchens have face frame cabinetry, some have frameless (or Eurobox as it is called). The opening of the individual cabinet must accommodate the width and height of the slide out unit. And then the depth must allow it to sit fully within your cabinet. Generally depth is not a problem. BUT, if you are considering mounting one of these units in your sink base cabinet, there is a strong possibility that your sink drain pipes are NOT going to allow it to fit. Most kitchens will have a large cabinet to the left or right of the sink. This would be a better option for the slide out unit. If you have a shelf in the cabinet, take out the shelf.
About door mounting:
Each unit out of the box is designed to work behind a hinged door. You open the door, reach in and pull out the waste bin system. If you use the overlay door mount bracket kit, you will remove the hinges from your door and attach the door to the slide out mechanism. Thus you pull out on the door and the waste bin unit comes out with the pull on the door. A very nice option to have. Easy to give it a soft kick to slide it back into your cabinet.
If you have any questions in advance, please ask us.
About shipping costs:
These units are big, they are assembled in their boxes, thus all of them ship as "dimensional size boxes." They may weigh only 12 to 15 pounds, but with UPS, they will ship at 28# to 50# dimensional weights. We set up most every order for the Hafele pull-out waste containers as a direct ship from Hafele. Some may come to us first and then we will ship. IF YOU WOULD LIKE a shipping quote in advance of ordering, please ask. If on the phone, we will give you an estimate which will be correct within a couple of dollars. If you e-mail us, that will give us a little time to e-mail a request to Hafele and ask them, being a bit more precise on the shipping cost.
Orders going to AK, HI, USVI, PR, Canada or anywhere else, please do let us get a shipping quote for you first. For any package that ships off the North American continent, shipping can become quite expensive, especially when dimensional size rates apply. Shipping across the border to Canada is always more expensive than shipping within the US. We do not want to sticker shock you on the shipping cost, which may happen anyway, but we do request, inquire about the shipping cost before ordering. We know for some customers, high shipping costs are a deal breaker. We are sorry about that, we do need to recover what we are being charged for shipping, and that is all we do. We DO NOT mark up shipping costs. It is wrong to profit on shipping. We abide by that.
Orders going outside the US, other than Canada, may not be too practical. Because of the sizes of these boxes, shipping costs can become quite ridiculous. We can quote shipping, but do not expect it to be a low amount. Larger or heavier boxes shipping internationally can become quite expensive.
Shipping charges are not automatically displayed in our shopping cart. That is why we encourage requesting knowledge of the actual amount prior to shipping. Orders are processed at Eclectic-ware by a person, not a auto robot on the website. One good thing is that Hafele has multiple locations in the US. Thus, we ask that they ship from the location closest to you to help reduce the shipping cost since cost is based on distance also.
